From The Anvil

Peardrop Slim 16mm Window Espag Handle

33333

£34.46
/
Tax included. Shipping calculated at checkout.
Finish
Handing
Size
  • Worldwide shipping
  • In stock, ready to ship
  • Inventory on the way

The Peardrop Slim 16mm Window Espagnolette Fastener is a simple, traditional looking product with the benefits of a modern and secure configuration. This is a popular choice for window security and offers the durability and weather resistance required for use in domestic and residential environments.

From then Anvil Peardrop Slim 16mm Window Espag Handle is designed by one person as a family company with two premises in mind. They design and manufacture products that are accessible and affordable to the general public without compromising on quality or design.

  • Designed to fit any type of window including uPVC and timber. Can be matched with the peardrop stays in the range.
  • The handle is hinged to ensure it can be lifted away from the window for ease of use.
  • The product is handed and therefore care needs to be taken when choosing the correct hand. From the inside view, if your window is hinged on the left then a left-hand fastener is required.
  • They have a 7mm² x 38mm spindle and can be locked by way of a grub screw.
  • Can be used with an espagnolette gearbox & window lock.
  • Supplied with matching SS M5 screws.

Overall Length: 124mm
Handle Length 104mm
Fixing Plate: 60mm x 18mm x 7mm

The antique pewter finish is the result of a complex process applied to solid brass, offering an attractive alternative to pewter patina. As this finish is applied to brass rather than steel, it has fewer textural marks making it smoother than the From the Anvil pewter patina finish.


Peardrop Slim 16mm Window Espag Handle - 33333 - Technical Drawing
